Pigsty v0.5: Declarative DB Templates

December 26, 2020 By vonng In Articles 684 words 4 min

Pigsty

vonng

Originally published on VONNG.

GitHub Release: https://github.com/pgsty/pigsty/releases/tag/v0.5.0

v0.5.0

Outline

The official docs site (http://pigsty.cc/) is live.
Database templating becomes fully declarative: define users, roles, databases, ACLs, extensions, and schemas in config.
The default access model is refined and HBA management now comes straight from Pigsty instead of Patroni.
Grafana provisioning switched from shoving a sqlite file to JSON provisioning via API.
Added the pg-cluster-replication dashboard to the open bundle.
CentOS 7.8 offline bundle: pkg.tgz.

Declarative Database Layouts

Multi-tenant headaches go away once everything is described as code. The new templates let you declare users, passwords, role hierarchies, DB defaults, extensions, schemas, and default privileges in YAML so a single config file replaces piles of runbooks. A stripped example:

# per-cluster settings
pg_users:
  - username: test
    password: test
    comment: default test user
    groups: [ dbrole_readwrite ]
pg_databases:
  - name: test
    extensions: [{name: postgis}]
    parameters:
      search_path: public,monitor

# environment-wide system roles
pg_replication_username: replicator
pg_replication_password: DBUser.Replicator
pg_monitor_username: dbuser_monitor
pg_monitor_password: DBUser.Monitor
pg_admin_username: dbuser_admin
pg_admin_password: DBUser.Admin

# default roles
pg_default_roles:
  - username: dbrole_readonly
    options: NOLOGIN
    comment: role for readonly access

  - username: dbrole_readwrite
    options: NOLOGIN
    comment: role for read-write access
    groups: [ dbrole_readonly ]

  - username: dbrole_admin
    options: NOLOGIN BYPASSRLS
    comment: role for object creation
    groups: [dbrole_readwrite,pg_monitor,pg_signal_backend]

  - username: postgres
    options: SUPERUSER LOGIN
    comment: system superuser

  - username: replicator
    options: REPLICATION LOGIN
    groups: [pg_monitor, dbrole_readonly]
    comment: system replicator

  - username: dbuser_monitor
    options: LOGIN CONNECTION LIMIT 10
    comment: system monitor user
    groups: [pg_monitor, dbrole_readonly]

  - username: dbuser_admin
    options: LOGIN BYPASSRLS
    comment: system admin user
    groups: [dbrole_admin]

  - username: dbuser_stats
    password: DBUser.Stats
    options: LOGIN
    comment: business read-only user for statistics
    groups: [dbrole_readonly]

# default privileges applied to dbsu/admin objects
pg_default_privilegs:
  - GRANT USAGE                         ON SCHEMAS   TO dbrole_readonly
  - GRANT SELECT                        ON TABLES    TO dbrole_readonly
  - GRANT SELECT                        ON SEQUENCES TO dbrole_readonly
  - GRANT EXECUTE                       ON FUNCTIONS TO dbrole_readonly
  - GRANT INSERT, UPDATE, DELETE        ON TABLES    TO dbrole_readwrite
  - GRANT USAGE,  UPDATE                ON SEQUENCES TO dbrole_readwrite
  - GRANT TRUNCATE, REFERENCES, TRIGGER ON TABLES    TO dbrole_admin
  - GRANT CREATE                        ON SCHEMAS   TO dbrole_admin
  - GRANT USAGE                         ON TYPES     TO dbrole_admin

pg_default_schemas: [monitor]

pg_default_extensions:
  - { name: 'pg_stat_statements',  schema: 'monitor' }
  - { name: 'pgstattuple',         schema: 'monitor' }
  - { name: 'pg_qualstats',        schema: 'monitor' }
  - { name: 'pg_buffercache',      schema: 'monitor' }
  - { name: 'pageinspect',         schema: 'monitor' }
  - { name: 'pg_prewarm',          schema: 'monitor' }
  - { name: 'pg_visibility',       schema: 'monitor' }
  - { name: 'pg_freespacemap',     schema: 'monitor' }
  - { name: 'pg_repack',           schema: 'monitor' }
  - name: postgres_fdw
  - name: file_fdw
  - name: btree_gist
  - name: btree_gin
  - name: pg_trgm
  - name: intagg
  - name: intarray

pg_hba_rules:
  - title: allow meta node password access
    role: common
    rules:
      - host    all     all                         10.10.10.10/32      md5

  - title: allow intranet admin password access
    role: common
    rules:
      - host    all     +dbrole_admin               10.0.0.0/8          md5
      - host    all     +dbrole_admin               172.16.0.0/12       md5
      - host    all     +dbrole_admin               192.168.0.0/16      md5

  - title: allow intranet password access
    role: common
    rules:
      - host    all             all                 10.0.0.0/8          md5
      - host    all             all                 172.16.0.0/12       md5
      - host    all             all                 192.168.0.0/16      md5

  - title: allow local read-write access
    role: common
    rules:
      - local   all     +dbrole_readwrite                               md5
      - host    all     +dbrole_readwrite           127.0.0.1/32        md5

  - title: allow read-only access
    role: replica
    rules:
      - local   all     +dbrole_readonly                               md5
      - host    all     +dbrole_readonly           127.0.0.1/32        md5
pg_hba_rules_extra: []

pgbouncer_hba_rules:
  - title: local password access
    role: common
    rules:
      - local  all          all                                     md5
      - host   all          all                     127.0.0.1/32    md5

  - title: intranet password access
    role: common
    rules:
      - host   all          all                     10.0.0.0/8      md5
      - host   all          all                     172.16.0.0/12   md5
      - host   all          all                     192.168.0.0/16  md5
pgbouncer_hba_rules_extra: []

Templates and Permissions

Two SQL templates (pg-init-template.sql for template1 and pg-init-business.sql for business databases) now give you hooks to seed any custom logic. The default ACL layout was tightened for multi-tenant instances: regular users no longer get implicit CONNECT on foreign databases, CREATE on their own DB, or CREATE inside public.

Provisioning Updates

Grafana provisioning now happens through the API, so you can feed dashboards into an existing Grafana by simply pointing grafana_url at a username/password endpoint. Pigsty generates HBAs on its own so Patroni stays focused on HA, and the supply chain is cleaner.
